Draftings Australia supplies CAD drafting to Melbourne builders, developers, engineers, and manufacturers — working drawings for volume and custom home builders, town planning and building permit sets for multi-unit developments in the growth corridors, and mechanical drafting for the manufacturing belt in the city’s south-east. We slot into your workflow as overflow capacity or run the full documentation scope.
CAD Drafting Services Available in Melbourne
What Melbourne clients bring to us most often:
- ResCode-aware documentation: overlooking, overshadowing, and garden-area diagrams prepared for Clause 54/55 assessment on Melbourne multi-unit sites
- Volume-builder throughput: repeatable working-drawing packages on your standard details and title block, priced per dwelling for predictable costing
- Manufacturing drafting: AS 1100 mechanical drawings and reverse-engineered models for the south-east industrial belt
- Turnaround that matches build programs: single-dwelling working drawings typically 3–5 business days; townhouse permit sets scoped and scheduled upfront
Melbourne Service Area
We provide CAD drafting services to clients throughout Greater Melbourne and Victoria, including the Melbourne CBD, Docklands, Southbank, St Kilda, Fitzroy, Brunswick, Dandenong, Laverton, Sunshine, Footscray, Box Hill, Ringwood, Frankston, Geelong, and Ballarat.
The Melbourne Work We See Most
Melbourne gives us two steady streams. The first is residential volume: working-drawing packages for builders delivering into the growth corridors — Tarneit and Truganina in the west, Craigieburn and Kalkallo in the north, Clyde and Officer in the south-east. These are repeatable sets on the builder’s standard details, where the value we add is consistency and per-dwelling pricing that lets the builder cost drafting into every contract before it is signed.
The second stream is the multi-unit infill market: dual occupancies and three-to-eight townhouse sites in the middle-ring suburbs, where the town planning set has to survive Clause 55 assessment and a neighbour objection or two. Shadow diagrams drawn at the September equinox, overlooking cones shown honestly, garden-area calculations that add up — the drawings either demonstrate compliance or they trigger an RFI, and we have drawn enough of these to know which details council planners in Melbourne actually check first.
Around those two streams sits the manufacturing work: reverse engineering and fabrication drawings for the workshops of the south-east, where a measured part becomes a model, a drawing, and a STEP file for the machinist within the week.
Get a Free Quote for CAD Drafting in Melbourne
Email your plans, markups, or a scope description and we will price the Melbourne work as a fixed quote within one business day.
📞 Melbourne direct line: 03 8376 6170
📞 National: 1800 287 223
📧 [email protected]
Do you prepare town planning drawings for Melbourne townhouse developments?
Yes. Multi-unit town planning sets are one of our largest Melbourne workstreams — site analysis, design response, floor plans, elevations, shadow diagrams at the September equinox, and the overlooking diagrams that Clause 55 assessment requires. We work with your town planner or directly with your architect to get the set through council with minimal RFIs.
Can you produce building permit drawings for a Victorian registered building surveyor?
We prepare working drawings and documentation to the level a registered building surveyor needs for permit issue — construction details, bracing and tie-down documentation coordinated with your engineer, and NCC-compliant specification notes. Many Melbourne builders send us the approved town planning set and we take it through to permit-ready working drawings.
Do you handle manufacturing and reverse engineering work in Melbourne?
A significant share of our Melbourne work comes from manufacturers in Dandenong, Clayton, and the wider south-east — measuring existing components and producing accurate CAD models and AS 1100 fabrication drawings for parts where original documentation is lost or never existed. We work in SolidWorks and AutoCAD and can deliver STEP files for your machinists.
Can you act as overflow drafting for a volume builder?
Yes, and this is where per-dwelling fixed pricing works best. We set up your standard details, title block, and layer conventions once, then turn around each working-drawing package to the same standard — so your drafting capacity scales with sales volume without hiring.
